High Pressure - BSP Products
Filters
Connection 1 + 2
BSPP female thread, parallel
Contact travel
0; 90
Customs tariff number
84818081
DN*
4
6
10
12
19
20
25
31
38
LW
10 mm
13 mm
20 mm
24 mm
25 mm
32 mm
38 mm
5 mm
6 mm
Material
steel housing, ball and operating shaft
Sealing form 1 + 2
for screw-in pins with types A, B and if necessary E
Surface
burnished
Temp. max.
80 C
Temp. min.
-20 C
Threads 1 + 2
1" BSP
G 1 -11
G 1.1/2 -11
G 1.1/4 -11
G 1/2 -14
G 1/4 -19
G 1/8 -28
G 3/4 -14
G 3/8 -19
Working Pressure
350 Bar
