IGRL B Products
Filters
D
20 mm
22 mm
25 mm
28 mm
45 mm
40 mm
35 mm
50 mm
36 mm
56 mm
55 mm
60 mm
80.7 mm
65 mm
90.7 mm
90 mm
100 mm
130 mm
L
3.2 mm
4.2 mm
Max. sliding velocity
15 m/s
Installation
first bend the O-ring and then the PTFE ring into a kidney shape
Application
hydraulic systems
Construction type
rod seal set
Material
(1) dynamic seal: PTBR
Media
mineral oil
Temp. max.
110 C
Temp. min.
-30 C
Working pressure
700 bar
Customs tariff number
39269097
